Sterling Analytical provides catalyst impurity testing focused on quantifying poisoning elements, trace metals, and contaminants that affect catalytic performance, specification compliance, and material value. Using ICP-OES and ICP-MS, we deliver clear, decision-ready data for refineries, catalyst manufacturers, and process engineers working with fresh, in-service, and spent catalyst materials.

During manufacturing, handling, and operation, catalysts can accumulate contaminants such as sulfur, phosphorus, arsenic, and lead—elements that bind active sites and reduce performance long before physical degradation is visible. At the same time, base metals like iron, sodium, and calcium build up from feedstock and equipment contact, impacting both process efficiency and downstream recovery value.

Reliable impurity testing supports everything from QC release to root-cause investigation and recovery optimization. For full lifecycle evaluation, this service is often paired with Spent Catalyst Analysis and Precious Metal Assay to better understand catalyst condition and residual value.

Matrix & Digestion

Accurate catalyst impurity testing depends on complete dissolution of complex catalyst matrices, including alumina, zeolite, silica, and carbon supports. Incomplete digestion is one of the most common causes of inaccurate results—especially in calcined or precious-metal-loaded systems.

Sterling Analytical uses microwave-assisted acid digestion aligned with EPA 3052 principles. Reagent systems are selected based on catalyst chemistry:

  • Nitric acid (HNO3) and hydrochloric acid (HCl) for base and precious metals
  • Hydrofluoric acid (HF) for alumina, silica, and zeolite breakdown
  • Hydrofluoric acid (HF) for alumina, silica, and zeolite breakdown
  • Boric acid stabilization post-digestion to neutralize HF

Closed-vessel digestion ensures full matrix breakdown and accurate recovery of embedded elements. For highly refractory materials or precious metal verification, additional preparation methods such as fusion or fire assay may be applied where appropriate.

Elements Reported & Typical Reporting Limits

Our catalyst impurity testing covers key poisoning elements and trace metals affecting catalyst performance and handling.

Typical analytes include:

  • Sulfur (S), Phosphorus (P), Arsenic (As), Lead (Pb), Mercury (Hg)
  • Silicon (Si), Iron (Fe), Sodium (Na), Calcium (Ca), Magnesium (Mg), Potassium (K)
  • Nickel (Ni) and other transition metals

Precious metals such as platinum (Pt), palladium (Pd), rhodium (Rh), and ruthenium (Ru) can also be included for loading verification or recovery evaluation.

Detection limits typically fall within low ppm ranges for ICP-OES, with sub-ppm capability available via ICP-MS Elemental Analysis when required. Final reporting limits depend on sample matrix and method selection and should be confirmed for your specific catalyst system.

Method Selection: ICP-OES vs. ICP-MS

ICP-OES is well suited for routine multi-element analysis across low ppm to percent-level concentrations, making it ideal for QC release, process monitoring, and general impurity screening.

For applications requiring higher sensitivity—such as catalyst poisons at trace levels or pharmaceutical-related specifications—ICP-MS Elemental Analysis provides sub-ppm and ppb-level detection. This ensures the analytical method aligns with your actual specification requirements.

Common Catalyst Contamination Problems Identified

Catalyst impurity testing frequently identifies:

  • Sulfur and phosphorus poisoning from feedstock contamination
  • Iron, sodium, and calcium buildup from corrosion or process carryover
  • Silicon deposition affecting pore structure and diffusion
  • Off-spec precious metal loading in fresh or regenerated catalyst
  • Cross-contamination between batches or storage environments

Many of these issues develop without visible signs, making routine impurity testing essential for maintaining performance and avoiding unplanned downtime.

Sample Quantity & Handling

Recommended sample size: 5–10 grams of representative material.

Accepted forms include pellets, extrudates, powders, and beads.

Best practices:

  • Use sealed HDPE or polypropylene containers
  • Avoid glass where HF digestion may be used
  • Ensure the sample is well-mixed and representative
  • Provide catalyst type, batch ID, and service condition (fresh, spent, regenerated)

For localized deactivation studies, sampling from multiple or reactor zones is recommended.

Turnaround Time & Pricing

Standard turnaround time is 3–5 business days, with 24–48 hour rush service available for urgent investigations.

Pricing depends on element panel, detection limits, and digestion complexity. Cost-effective options are available for routine QC programs and multi-sample submissions.

What You Receive

Each project includes a detailed Certificate of Analysis (COA) suitable for technical and commercial use.

Your report includes:

  • Elemental composition (ppm or %) via ICP-OES or ICP-MS
  • Full impurity profile covering poisoning and trace elements
  • Method references and digestion notes
  • Reporting limits and data qualifiers
  • Quality control summary (calibration, duplicates, spikes)

All data is supported by CRM-traceable calibration, ensuring defensible results for compliance, troubleshooting, and recovery valuation.

Methods & Standards

  • EPA 3052 – Microwave-assisted acid digestion
  • SW-846 6010 – ICP-OES elemental analysis
  • ICP-MS for trace and ultra-trace detection
  • Calibration using certified reference materials (CRMs)

Request a Quote

Ready to move forward with catalyst impurity testing?

Tell us your catalyst type, elements of concern, and required detection limits—we’ll confirm the appropriate method, pricing, and turnaround within one business day.

Request a Quote
Speak with a Specialist

Frequently Asked Questions

What is catalyst impurity testing used for?
it is used to detect and quantify poisoning elements and trace metals that impact catalyst performance, supporting QC release, troubleshooting, and recovery valuation.
How much catalyst sample do I need to submit?
Typically 5–10 grams of representative material is sufficient. Contact the lab if sample availability is limited.
What’s the difference between ICP-OES and ICP-MS for catalyst testing?
ICP-OES is ideal for multi-element analysis at ppm to percent levels, while ICP-MS provides much lower detection limits for trace and ultra-trace analysis.
How long does catalyst impurity testing take?
Standard turnaround is 3–5 business days, with 24–48 hour rush service available.
Can you test for elements specific to my catalyst chemistry?
Yes, custom analyte panels can be developed based on your catalyst formulation and process requirements.
